Laser Pumps & Dispensers
Compac’s Laser Pumps and Dispensers are designed specifically for retail applications.
Our pumps and dispensers have many benefits and features, including:
- Stainless steel construction for all panels and doors
- Non wearing high performance COM50 or COM125 meter
- C4000 electronics approved for use in Class 1 Zone 1 hazardous areas
- Large display 6 x 25mm digits for money and volume with backlighting
- Easy to Service Most pipe connections are flanged minimising screwed connections and speeding up service.
- Laser model has strong Himasts that won't distort after drive away
Compac pumps and dispensers can operate standalone or controlled by a Compac Pump Controller or by a third party pump controller using one of the following:
- New Zealand communications protocol
- Gilbarco Australia communications protocol
- Gilbarco USA communications protocol
- Compac RS232 interface
All our pumps and dispensers have New Zealand and Australian approvals so there are no issues with compliance. Please go to the resources section to view or download copies.
Compac pumps and dispensers can also be individually tailored to suit your needs:
- Card reader models are available with a vapour barrier for use with card readers, pinpads and receipt printers
- Preset pads for accurate dispensing are available on most models
- Hose assembly to suit market with a range of breakaways and nozzles available
- Customised look dispensers powdercoated to your colours with custom decals
- Protocol available in Compac or Gilbarco
- Fuel options include 91, 98, Diesel, Avgas, Jet, Ethanol, Biodiesel
- Other requests can be discussed
Our pumps and dispensers are available from 40 to 160 lpm models:
Laser Models | Pump | Dispenser |
One hose, one product, 40lpm | L40P | L40S |
Two hoses, one product, 40lpm | L40PD | L40SD |
Two hoses, two products, 40lpm | LL40P | LL40S |
Four Hose, two products, 40lpm | LL40PQ | LL40SQ |
One hose, one product, 80 lpm | L80P | L80S |
One hose, one product, 160 lpm | L160P | L160S |
Two hoses, two products, 80 lpm | LL80P | LL80S |
Two hoses, two products, 160 lpm | - | LL160S |
Two hoses, two products, 160 lpm Side A, 80 lpm Side B |
- | LL160/80S |
